Product introduction:
The product is generally recognized as good fireproof and thermal insulation boards for steel
structure buildings. Its thermal conductivity is low, good load resistance, high bending strength,
no water absorption, no decay, no moth eaten rat bite, good flame retardancy, high degree
of fire resistance, large temperature range. This new light building material is the perfect combination
of color coated steel sheet and polyurethane, and is the development direction of light building materials.
Advantages:
1,It has high porosity and excellent energy saving effect.
2,Green environmental protection, formaldehyde free.
3,One input and sustained savings.
4,It has stronger ability to resist negative wind pressure because of its unique connection design.
5,Various styles, beautiful and elegant advantages: no cold bridge, big rigidity, good flatness.
6,Close interfacing, no heat conduction of steel plate.
7,Side sealing of polyurethane on both sides to block the water absorption path of core materials
and extend the service life.
8,Good fire protection performance: it is applicable to the walls and roof of large public buildings,
industrial plants and other buildings with fire protection requirements.
Basic Info:
Plate material | Galvanized steel sheet |
Core material | Polyurethane and fiberglass |
Thickness of steel plate | 0.4-0.8mm |
Thickness of Sandwich board | 50 /75/100/120/150mm |
Common width | 930/950/1000mm |
Length | As transportation equipment |
Heat resistant | >1000ºC |
Fire rating | B1 |
Sound insulation | 29~30 dB |
sound-absorbing | 15.7 dB |
Coefficient of thermal conductivity | 0.043 W / m2 K |
Average daily installation area | 600~800m2. |
Origin | China |
